LoRaWAN Ultrasonic Valve Controlled Smart Water Meter

  • Price: Negotiable
  • MOQ: 50 SQM
  • NRC: 0.88 from ISO354
  • Fire protection performance: Class A
  • Eco-Friendly: E1

LoRaWAN Ultrasonic Valve Controlled Smart Water Meter

Ultrasonic water meter is used to accurately measure the flow rate. The product has the characteristics of beautiful appearance, convenient installation, accurate measurement, stable operation, strong anti-pollution and anti-corrosion capability, long service life, small pressure loss, economy and practicality, etc. It is suitable for flow metering and charging of domestic water, central air conditioning system water, etc.

Features of Ultrasonic Valve Controlled Smart Water Meter

  • There are no moving parts in the ultrasonic water meter body, whether mechanical wear or measurement accuracy both can be maintained for a long time.
  • A large range ratio and a small initial flow rate, and very small starting flow.
  • The measurement accuracy is after operation, but factory inspection can be required according to Class 1 accuracy standard.
  • Fluid temperature changes, and can achieve T30/T50/T70 temperature grade.
  • Strong anti-static(more than 12000V) and anti-magnetic interference capabilities.
  • Adopts micro-power consumption design technology to minimize the comprehensive power consumption of the water meter and has a service life of more than 6 +2 years.
  • Select multiple communication modes(NB-IOT LoRa, LoRaWAN, M-Bus. RS485, pulse and other communications)
  • Long-term data storage.
  • Water flow direction recognition mechanism, which can measure the positive and negative flow.
  • Long time water running (leakage alarm)  alarm mechanism and an oath reporting mechanism.
  • Empty pipe alarm mechanism, which can be used as an abnormal disassembly alarm after a long period of normal water running.
  • Judgment mechanism of false counting (instantaneous excessive flow metering).
  • Metering the fluid temperature, and can give low or high temperature alarm.
  • Domestic water care mechanism.
  • Valve control function.


HKT provides customized services:

  • ODM
  • Pre-sales & After-sales Services
  • Technology Support


Product Specifications

Parameters Description
Caliber DN15 DN20 DN25
Minimum Flow (Q1) 0.01 0.016 0.025
Common Flow (Q2) 2.5 4 6.3
Maximum Flow (Q3) 3.125 5 7.9
Range Ratio 250
Accuracy class B Class
Working pressure ≤ 1. 6MPa
Pressure loss Δp40
Ingress protection IP65,IP68(optional)
Operating water temperature 5~ 55℃
Communication mode LoRaWAN/NB/GPRS/RS485
Power supply 3.6 V
Button Magnetic induction button
Screen LCD8bit
Display range 0m³~+99999.999m³


No. Item Unit Quantity
1 Ultrasonic Valve Controlled Water Meter Piece 1
2 Coupling and sealing washer(optional) Piece 2
